Modular Pilot Operated Check Valve

Get a Price/Quote

MOQ : 1 Piece

Modular Pilot Operated Check Valve Specification

Product Name
Modular Pilot Operated Check Valve

Type
Pilot Operated, Modular Mounting Type

Material
High-Strength Steel with Corrosion Resistant Coating

Power
Hydraulic

Pressure
Max. 315 bar (4570 psi)

Structure
Sandwich-type modular body

Size
Available in NG06 (Cetop 3), NG10 (Cetop 5)

Weight
Approx. 2.1 kg (for NG06 size)

Temperature
-20C to 80C

Max Flow Rate
Up to 60 LPM (NG06), up to 120 LPM (NG10)

Serviceability
Field serviceable, with replaceable internal components

Port Threads
As per ISO mounting block specifications

Seals
Nitrile (NBR) standard, Viton optional

Application
Hydraulic circuits requiring load holding or safety locking

Hydraulic Medium
Mineral oil or compatible fluids

Flow Direction
One-way check, pilot to release

Leakage
Virtually zero leakage in checked direction

Response Time
Fast acting with low pressure drop

Surface Finish
Phosphated or painted for enhanced corrosion resistance

Manufacturer's Warranty
Typically 12 months from date of supply

Mounting Interface
ISO 4401 / CETOP / NFPA standard patterns

Pilot Ratio
4:1 standard, others available on request

Modular Pilot Operated Check Valve Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Pieces Per Month

Delivery Time
07 Days

About Modular Pilot Operated Check Valve

Experience the grand sophistication and ultimate efficiency of our Modular Pilot Operated Check Valve, engineered for affordability without compromising performance. Utilise this premium offer to secure optimal savings while maintaining trust in a paragon of hydraulic technology. Built from high-strength steel with corrosion-resistant coating, this valve fits ISO 4401 / CETOP / NFPA interface standards and delivers virtually zero leakage in checked direction. With pilot ratios of 4:1, flow rates up to 120 LPM, superior serviceability, and field-replaceable components, it provides steadfast load holding and safety locking for hydraulic circuits. Make the smart, affordable choice with our proven quality promise.

Special Features & Application Highlights

The Modular Pilot Operated Check Valve boasts swift response, robust load holding, and reliable safety locking, making it essential for hydraulic circuits in industrial machinery, mobile equipment, and material handling systems. Its sandwich-type modular construction ensures easy integration and application flexibility. With field-replaceable internals and a choice of high-quality seals, it stands as the ultimate option for applications demanding virtually leak-free performance. Ideal for energy-efficient, safety-sensitive operations requiring pressure control and load retention.

Main Domestic Market, Logistics & Certifications

Our premium Modular Pilot Operated Check Valves are predominantly supplied across India's main domestic industrial hubs, ensuring timely delivery via trusted goods transport partners. Each unit is meticulously packed and dispatched, upholding the highest standards of quality. Payment terms are customer-friendly, including advance or milestone-based options. The product adheres to respected industrial certifications, reinforcing its compliance and reliability. Enjoy peace of mind knowing your purchase is supported by warranty, trusted packing, and professional logistics management.

FAQ's of Modular Pilot Operated Check Valve:

Q: How does the Modular Pilot Operated Check Valve enhance hydraulic circuit safety?

A: The valve provides a dependable one-way check while allowing pilot release as required, ensuring secure load holding and preventing unintended movement in hydraulic circuits. Its design minimizes leakage, enhancing overall safety.

Q: What applications benefit most from using this valve type?

A: This valve is ideal for machinery and systems that require precise load retention and safety locking, such as material handling equipment, construction machines, and various industrial hydraulic circuits.

Q: How can I utilise available offers to maximise savings on bulk purchases?

A: By contacting our sales team or authorised traders, you can access exclusive deals and volume discounts, allowing you to capitalise on affordable procurement and maximise your overall savings.

Q: Where is this valve commonly used in India?

A: The Modular Pilot Operated Check Valve is widely used by industries located in major domestic manufacturing and process hubs across India, owing to its conformance with leading hydraulic interface standards.

Q: What is the process for field servicing the valve, and how easy is maintenance?

A: The valve features a service-friendly design with replaceable internal components, making routine maintenance or part replacement straightforward. This ensures extended service life and minimal downtime.

Q: When is it advisable to choose Viton seals over standard Nitrile?

A: Viton seals are recommended for applications involving higher operating temperatures or aggressive hydraulic fluids where standard Nitrile seals may not provide optimal chemical resistance.
